AXIstorage Li SV1 16.9 + AXIhycon 10H

Axitec from head to toe - in our case rather from roof to cellar. Axitec now completes its quality chain with the new AXIhycon hybrid inverter series. Of course compatible with the in-house high-voltage storage systems AXIstorage Li SV1 and SV2. Up to 16 amps input current per MPP tracker as well as integrated arc monitoring and type 2 overvoltage protection leave little to be desired. A backup function at UPS level also adds further plus points.

Product benefits:

• Emergency power with UPS function < 10ms

• 16 A input current per MPPT

• Integrated AFCI and DC overvoltage protection type 2

• Storage expandable up to 23.6 kWh

Product features System:

• AC power: 10.0 kW

• AC connection: 3-phase

• Number of MPPT: 2

• Input current: 16A per MPPT

• DC connection: MC4

• Communication: WLAN (opt.), Ethernet, CAN, RS485

• Protection class: IP66

• Cooling: passive

• Weight: 32.6 kg

• Dimensions: 600 x 500 x 230 mm (W x H x D)

• Energy meter included with inverter

Product features Storage:

• Battery capacity (usable): 16.9 kWh

• Time window expansion: 5 years

• Cell chemistry: LFP

• Rated voltage: 240 V

• Protection class: IP55

• Dimensions: 1040 x 600 x 380 mm (H x W x D)

• Weight: BCU 25.0 kg, 5x storage 40.0 kg each

Conclusion:

The new trend of "everything from a single source" is now also available from Axitec. Quality from roof to cellar.

Scope of delivery:

• 1x AXIhycon 10H hybrid inverter, incl. meter (item 0154682)

• 1x Axitec AXIstorage Li SV1 BCU (item 0152358)

• 5x Axitec AXIstorage Li SV1 storage module (item 0150754)
