Smart Power Sensor SmartPS-250A-T0

With the SmartPS-250A-T0 smart meter, energy flows at the grid connection point can be quickly and accurately recorded to enable storage charging management and visualization of self-consumption. This indirect measuring version comes with three measuring transformers with 250 A primary current.

Product features:

? Grid connection: 400 V

? Connection phases: 3

? Measurement: indirect

? Primary current: 250 A

? Secondary current: 50 mA

? Communication: RS485 (Modbus-RTU)

? Mounting: DIN rail

? Dimensions: 100 x 72 x 66 mm (H x W x D)

? Weight: approx. 1.5 kg
