Argeno 125
  • Argeno 125

Argeno 125

0158404
Fronius
€6,238.69
Tax excluded
€7,548.81 Tax included
Quantity

Ask about the product on WhatsApp
Description

Product information "Argeno 125"

An additional plant controller/EMS is required for connecting radio remote control receivers, power controllers and so on.
The Argeno 125 from Fronius is the new player for the commercial segment. With 10 MPP trackers and a 30-amp input current each, it offers high flexibility. A high level of safety is ensured by integrated Type 1+2 surge protection on both AC and DC connections. Thanks to open interfaces, it offers universal application possibilities for energy management with Wattpilot, Ohmpilot, and similar systems. The integrated data logger also features numerous connection options for external control signals or load management.

Product advantages:
? 30 A input current per MPPT / 20 A per string
? Integrated and interchangeable AC+DC overvoltage protection type 1+2
? Integrated data logger + web server

Product features:
? AC power: 125.0 kW
? AC connection: 400 V, 3-phase
? Number of MPPT: 10
? Connections per MPPT: 2
? DC input current: 30 A per MPPT / 20.0 A per string
? DC connector: Phoenix Contact SUNCLIX (counterparts included in the scope of delivery)
? Overvoltage protection: Type 1+2 on AC+DC with interchangeable elements
? Communication: 2 x Ethernet
? Interfaces: WSD (Wired Shutdown)
? Protection class: IP66
? Cooling: active
? Dimensions: 1070 x 755 x 330 mm (H x W x D)
? Weight: 90.0 kg
Product Details
0158404
GPSR

Brand: Fronius
