MultiCoax MC100/4 zwart 100mtr. 4 in 1 PVC
  • MultiCoax MC100/4 zwart 100mtr. 4 in 1 PVC

MultiCoax MC100/4 zwart 100mtr. 4 in 1 PVC

TRX.731073
BCK
Triax 18MULTI 4-voudige multicoax
€ 649,00
€ 649,00 € 536,36 € 649,00 € 536,36
Inclusief belasting Inclusief belasting Exclusief belasting Inclusief belasting Exclusief belasting
€ 536,36 Exclusief belasting
€ 649,00 Inclusief belasting
€ 112,64 BTW
€ 536,36 Exclusief belasting
€ 112,64 BTW
€ 649,00 Inclusief belasting
Aantal
Out of stock (please inquire about delivery time)

Vraag naar het product op WhatsApp
Omschrijving

Multicoax 4-voudig met kleurcodering

Deze 4-voudige multicoax (6,7 mm) zit in een zwarte PVC-mantel. De coax multikabel zit op een rol van 100 meter. De drievoudig afgeschermde kabel is voorzien van een koperen binnengeleider en staat garant voor lage signaaldemping. De kleurcodering van de 4 coaxkabels maakt deze 4-in-1 coaxkabel ideaal voor gebruik met multiswitch-systemen (zonder terrestrisch). De kabel is bedoeld voor gebruik binnen.

Technische specificaties 4-voudige multicoax

  • Binnengeleider (kern)
    • Materiaal: Cu
    • Diameter: 1,13 mm (± 0,01)
  • Afscherming (folie, eerste)
    • Materiaal: Al/Pet/Al
  • Afscherming (vlecht, tweede)
    • Materiaal: AI
    • Dekking: 43% (± 2%)
  • Afscherming (folie, derde)
    • Materiaal: AL/Pet (gebonden)
    • Afmeting: 9 um/12 um mm
  • Buitenmantel
    • Materiaal: PVC
    • Diameter:
      • Enkele coaxkabel: 6,8 mm (± 0,2)
      • Uitwendig: 26,2 mm (± 1,5)
    • Screening attenuation @ 30-1000 MHz: > 85 dB
    • Screening attenuation @ 1000-2000 MHz: > 75 dB
    • Screening attenuation @ 2000-3000 MHz: > 65 dB
    • Demping (20°C/100mtr) @ 5 MHz: 2,1 dB
    • Demping (20°C/100mtr) @ 50 MHz: 4,9 dB
    • Demping (20°C/100mtr) @ 200 MHz: 10 dB
    • Demping (20°C/100mtr) @ 400 MHz: 14,4 dB
    • Demping (20°C/100mtr) @ 800 MHz: 19 dB
    • Demping (20°C/100mtr) @ 1000 MHz: 22,5 dB
    • Demping (20°C/100mtr) @ 1350 MHz: 25 dB
    • Demping (20°C/100mtr) @ 1750 MHz: 29 dB
    • Demping (20°C/100mtr) @ 2150 MHz: 32 dB
    • Demping (20°C/100mtr) @ 2400 MHz: 34,2 dB
    • Demping (20°C/100mtr) @ 3000 MHz: 38,5 dB
    • Structureel retourverlies @ 5-470 MHz: ≥ 18 dB
    • Structureel retourverlies @ 470-1000 MHz: ≥ 16 dB
    • Structureel retourverlies @ 1000-2400 MHz: ≥ 12 dB
    • Structureel retourverlies @ 2000-3000 MHz: ≥ 12 dB
    • Impedantie: 75 Ω (± 5
    • Capaciteit: 52,0 pF/m (± 3)
    • Inner DC resistance: < 21,3 Ω/km
    • Outer DC resistance: < 40 Ω/km
    • Toepassing: binnen
    • Certificering: Klasse A (EN 50117)
    • Kabellengte: 100 meter
    • Minimale buigradius (enkel/herhaald): 190 mm
    • Kleur: RAL9004 (zwart)
